NovaStar VX400 All-in-One LED Video Screen Controller

Description

The NovaStar VX400 All-in-One LED Video Controller is a powerful LED display processor that combines advanced video processing and sending capabilities in one compact device. It supports a maximum loading capacity of 2.6 million pixels, with output resolutions up to 10,240 × 8,192 pixels, making it suitable for medium-sized LED displays, stage events, rental applications, digital signage, and fine-pitch LED video walls.

Featuring 4 Gigabit Ethernet outputs, 2 × 10G optical fiber outputs, HDMI, DVI, and 3G-SDI inputs, the VX400 delivers flexible connectivity for professional AV systems. Advanced features such as free image scaling, ultra-low latency, pixel-level brightness and chroma calibration, color adjustment, and 10customizable presets ensure exceptional image quality and reliable performance. Compatible with NovaLCT and V-Can software, the NovaStar VX400 offers efficient configuration, monitoring, and management for demanding LED display installations.LED Video Processor

Brand

NovaStar

Model

VX400

Product Type

All-in-One LED Video Controller

Maximum Loading Capacity

2.6 Million Pixels

Maximum Width

10,240 Pixels

Maximum Height

8,192 Pixels

Ethernet Outputs

4 × Gigabit Ethernet Ports

Optical Fiber Outputs

2 × 10G Optical Fiber Ports

HDMI Inputs

2 × HDMI 1.3

HDMI Loop Output

1 × HDMI 1.3 Loop

DVI Input

1 × DVI

DVI Loop Output

1 × DVI Loop

SDI Input

1 × 3G-SDI

SDI Loop Output

1 × 3G-SDI Loop

Monitoring Output

1 × HDMI 1.3

USB Ports

USB 2.0

Control Port

Gigabit Ethernet

Display Layers

2 Layers (1 Main + 1 PIP)

Scaling

Free Scaling & Seamless Switching

Low Latency

Supported (Ultra-Low Latency Mode)

3D Display

Supported

Pixel-Level Brightness Calibration

Supported

Pixel-Level Chroma Calibration

Supported

Color Adjustment

Brightness, Contrast, Saturation, Hue & Gamma

Presets

Up to 10 User-Defined Presets

Working Modes

Video Controller, Fiber Converter, Bypass

Software

NovaLCT, V-Can

Power Supply

AC 100–240V, 50/60Hz

Power Consumption

28W

Dimensions

483.6 × 301.2 × 50.1 mm

Weight

4.0 kg

Applications

Rental LED Displays, Stage Events, Broadcast Studios, Conference Rooms, Digital Signage, Fine-Pitch LED Displays
